RT / RTx Engine Control Module (ECM) Diagnostics
5.3 ECM Monitoring of Solenoids—Kohler Engine Only
The ECM monitors the wiring to, and condition of, the fuel solenoid and the wiring
to, and condition of, the starter solenoid.
If the wire (a) to the fuel solenoid is
disconnected or the fuel solenoid is faulty,
the following results occur.
■ The control panel indicators (b) will flash
immediately after the transmitter is turned
on.
■ The red LEDs of the light ring will
illuminate solid red.
■ The engine will not crank.
Reconnect the wire or replace the fuel
solenoid to enable the machine to start.
If the wire (c) to the starter solenoid is
disconnected or the starter solenoid is faulty,
the following results occur.
■ The control panel indicators will flash
immediately after the starter pushbutton is
pressed.
■ The red LEDs of the light ring will
illuminate solid red.
■ The engine will not crank.
Reconnect the wire or replace the starter
solenoid to enable the machine to start.
