RT / RTx General Maintenance
7.5 Lubricating the Articulated Joint and Steering Cylinders
Lubricate top and bottom bearing blocks (a) and cylinder knuckles (b) every 100
hours using a hand-held grease gun. Cylinder knuckles can be accessed through
holes on side of machine (c).
Use Mobil XHP222 or an equivalent No. 2 general purpose grease.
wc_gr012192
c
b
a
c
a
