RT / RTx Engine Control Module (ECM) Diagnostics
5 Engine Control Module (ECM) Diagnostics
5.1 Overview of the ECM and the Diagnostic Tool
The RT-SC3 Roller features an Engine Control Module (ECM) with diagnostic and
programmable abilities. The diagnostics are conveyed via alpha-numeric codes
displayed on three LED displays that are viewable through the plastic case of the
ECM. These diagnostic/program abilities include:
■ The ability to view the stages of engine start-up.
■ The ability to view seven fault conditions and over 35 error codes.
■ The ability to lockout or allow engine start after a machine tip-over.
A diagnostic tool, which comes standard with the machine, is used to interface with
the ECM.
