5.3.3.2 Analog Input Flowmeter Address Map
Analog Input Flowmeter Address Map (W900 Controller Only)
Address
Name
Data Encoding
Permissions
Value
0
Primary Value 32-Bit Float Read
Flow Units
Rate Units
1
2
Primary Raw Value 32-Bit Float Read mA
3
4
Last Calibration Date 32-Bit Integer Read Unix Time
5
6
Flow Total 32-Bit Float Read Flow Units
7
8
Input Filter 32-Bit Float Read/Write mA
9
10
Deadband 32-Bit Float Read/Write
Flow Units
Rate Units
11
12
Smoothing Factor 32-Bit Float Read/Write 0 – 90%
13
14
LoLo Alarm Setpoint 32-Bit Float Read/Write
Flow Units
Rate Units
15
16
Low Alarm Setpoint 32-Bit Float Read/Write
Flow Units
Rate Units
17
18
High Alarm Setpoint 32-Bit Float Read/Write
Flow Units
Rate Units
19
20
HiHi Alarm Setpoint 32-Bit Float Read/Write
Flow Units
Rate Units
21
22
23
24
25
Reset Total Flow
Boolean
Read/Write
Write 1 to Reset Flow Total
26
27
28
Low Alarm
Boolean
Read
1 = Alarm Active
29
High Alarm
Boolean
Read
1 = Alarm Active
30
LoLo Alarm
Boolean
Read
1 = Alarm Active
31
HiHi Alarm
Boolean
Read
1 = Alarm Active
32
Cal Required
Boolean
Read
1 = Alarm Active
33
Input Failure
Boolean
Read
1 = Alarm Active
34
Status
16-Bit Status
Read
See 5.4 Status Register Codes
35
Alarm Bitfield
16-Bit Bitfield
Read
See 5.5.3 Sensor Input Alarm Bitfield
