5.3.6.14 Relay Output / Percent Timer Control Mode Address Map
Relay Output / Percent Timer Control Mode Address Map
Address
Name
Data Encoding
Permissions
Value
0
Time On 32-Bit Integer Read Seconds
1
2
Total Time 32-Bit Integer Read Seconds
3
4
Cycle Time 32-Bit Integer Read Seconds
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Feed Percentage 32-Bit Float Read/Write 0 – 100%
21
22
Feed Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
23
24
25
26
27
28
Hand Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
29
30
31
Relay State
Boolean
Read
0 = Off, 1 = On
32
Reset Time Total
Boolean
Read/Write
Write 1 to Reset Time Total
33 HOA Setting 16-Bit Integer Read/Write
0 = Hand, 1 = Off,
2 = Auto Mode
34
Status
16-Bit Integer
Read
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.6 Relay Output Alarm Bitfield
When accessed as a Coil,
Returns 1 if any alarm is active
