5.3.6.17 Relay Output / Spike Control Mode Address Map
Relay Output / Spike Control Mode Address Map
Time On 32-Bit Integer Read Seconds
Total Time 32-Bit Integer Read Seconds
Spike Event Time 32-Bit Integer Read Seconds
Setpoint 32-Bit Float Read/Write Input Sensor Units
Spike Setpoint 32-Bit Float Read/Write Input Sensor Units
Deadband 32-Bit Float Read/Write Input Sensor Units
Duty Cycle 32-Bit Float Read/Write 0 – 100%
Event 3 Start Time 32-Bit Integer Read/Write
0 – 86,399
Event 3 Duration 32-Bit Integer Read/Write 0 – 86,399 Seconds
Event 2 Start Time 32-Bit Integer Read/Write
0 – 86,399
Event 2 Duration 32-Bit Integer Read/Write 0 – 86,399 Seconds
Event 1 Start Time 32-Bit Integer Read/Write
0 – 86,399
Seconds Since Midnight
Event 1 Duration 32-Bit Integer Read/Write 0 – 86,399 Seconds
Hand Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
Write 1 to Reset Time Total
33 HOA Setting 16-Bit Integer Read/Write
0 = Hand, 1 = Off,
2 = Auto Mode
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.6 Relay Output Alarm Bitfield
When accessed as a Coil,
Returns 1 if any alarm is active
