Walchem W600 - Virtual Input Address Maps; Virtual Input; Calculation & Raw Value Type Address Map

28
5.3.5 Virtual Input Address Maps
5.3.5.1 Virtual Input / Calculation & Raw Value Type Address Map
Virtual Input / Calculation & Raw Value Type Address Map
Address
Name
Data Encoding
Permissions
Value
0
Primary Value 32-Bit Float Read Virtual Input Units
1
2
3
4
5
6
7
8
9
10
Deadband 32-Bit Float Read/Write Virtual Input Units
11
12
Smoothing Factor 32-Bit Float Read/Write 0 – 90%
13
14
LoLo Alarm Setpoint 32-Bit Float Read/Write Virtual Input Units
15
16
Low Alarm Setpoint 32-Bit Float Read/Write Virtual Input Units
17
18
High Alarm Setpoint 32-Bit Float Read/Write Virtual Input Units
19
20
HiHi Alarm Setpoint 32-Bit Float Read/Write Virtual Input Units
21
22
23
24
25
26
27
28
Low Alarm
Boolean
Read
1 = Alarm Active
29
High Alarm
Boolean
Read
1 = Alarm Active
30
LoLo Alarm
Boolean
Read
1 = Alarm Active
31
HiHi Alarm
Boolean
Read
1 = Alarm Active
32
33 Misc. Alarm Boolean Read
1 = Out-Of-Range or
Input Failure Alarm Active
34
Status
16-Bit Status
Read
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.5 Virtual Input Alarm
Bitfield
