5.3.6.16 Relay Output / Biocide Timer Control Mode Address Map
Relay Output / Biocide Timer Control Mode Address Map
Address
Name
Data Encoding
Permissions
Value
0
Time On 32-Bit Integer Read Seconds
1
2
Total Time 32-Bit Integer Read Seconds
3
4
Cycle Time 32-Bit Integer Read Seconds
5
6
Bleed Lockout 32-Bit Integer Read/Write 0 – 86,399 Seconds
7
8
Prebleed To
Setpoint
32-Bit Float Read/Write Input Sensor Units
9
10
Prebleed Time 32-Bit Integer Read/Write 0 – 86,399 Seconds
11
12
Event 4 Start Time 32-Bit Integer Read/Write
0 – 86,399
Seconds Since Midnight
13
14
Event 4 Duration 32-Bit Integer Read/Write 0 – 86,399 Seconds
15
16
Event 3 Start Time 32-Bit Integer Read/Write
0 – 86,399
Seconds Since Midnight
17
18
Event 3 Duration 32-Bit Integer Read/Write 0 – 86,399 Seconds
19
20
Event 2 Start Time 32-Bit Integer Read/Write
0 – 86,399
Seconds Since Midnight
21
22
Event 2 Duration 32-Bit Integer Read/Write 0 – 86,399 Seconds
23
24
Event 1 Start Time 32-Bit Integer Read/Write
0 – 86,399
Seconds Since Midnight
25
26
Event 1 Duration 32-Bit Integer Read/Write 0 – 86,399 Seconds
27
28
Hand Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
29
30
Active Timer Event
16-Bit Integer
Read
Event Number
31
Relay State
Boolean
Read
0 = Off, 1 = On
32
Reset Time Total
Boolean
Read/Write
Write 1 to Reset Time Total
33 HOA Setting 16-Bit Integer Read/Write
0 = Hand, 1 = Off,
2 = Auto Mode
34
Status
16-Bit Integer
Read
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.6 Relay Output Alarm Bitfield
When accessed as a Coil,
Returns 1 if any alarm is active
