5.3.5.3 Virtual Input / Disturbance Type Address Map
Virtual Input / Disturbance Type Address Map (W900 Controller Only)
Address
Name
Data Encoding
Permissions
Value
0
Primary Value 32-Bit Float Read Unitless
1
2
3
4
5
6
Minimum Value 32-Bit Float Read/Write Unitless
7
8
Maximum Value 32-Bit Float Read/Write Unitless
9
10
11
12
Smoothing Factor 32-Bit Float Read/Write 0 – 90%
13
14
15
16
17
18
19
20
21
22
Disturbance Setpoint 32-Bit Float Read/Write Disturbance Input Units
23
24
Max Disturbance 32-Bit Float Read/Write Disturbance Input Units
25
26
27
28
29
30
31
32
33
34
Status
16-Bit Status
Read
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.5 Virtual Input Alarm
Bitfield
