Walchem W600 - Analog Output; Lag Output Control Mode Address Map

65
5.3.8.7 Analog Output / Lag Output Control Mode Address Map
Analog Output / Lag Output Control Mode Address Map
Address
Field
Data Encoding
Permissions
Value
0
Time On 32-Bit Integer Read Seconds
1
2
Total Time 32-Bit Integer Read Seconds
3
4
Output 32-Bit Float Read Percent
5
6
Setpoint 1 ‡ 32-Bit Float Read/Write Input Sensor Units
7
8
Setpoint 2 ‡ 32-Bit Float Read/Write Input Sensor Units
9
10
Deadband ‡ 32-Bit Float Read/Write Input Sensor Units
11
12
Activation
Delay Time †‡
32-Bit Integer Read/Write 0 – 86,399 Seconds
13
14
Wear Level
Cycle Time †‡
32-Bit Integer Read/Write 10 – 86,399 Seconds
15
16
Current
Activation Time †‡
32-Bit Integer Read Seconds
17
18
Current Wear Level
Cycle Time †‡
32-Bit Integer Read Seconds
19
20
No. of Activated
Outputs †‡
16-Bit Integer Read Count
21
22
Output Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
23
24
25
26
27
28
29
30
Reset Output
Timeout
Boolean Read/Write Write 1 to Reset Output Timeout
31
32
Reset Time Total
Boolean
Read/Write
Write 1 to Reset Time Total
33 HOA Setting 16-Bit Integer Read/Write
0 = Hand, 1 = Off,
2 = Auto Mode
34
Status
16-Bit Status
Read
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.7 Analog Output Alarm Bitfield
When accessed as a Coil,
Returns 1 if any alarm is active
† Field is only defined for Lag Outputs configured as the “Last Lag” in the chain.
‡ Field is only meaningful for certain configurations of Lead-Lag chains.
