Walchem W600 - Analog Output; Disturbance Control Mode Address Map

64
5.3.8.6 Analog Output / Disturbance Control Mode Address Map
Analog Output / Disturbance Control Mode Address Map (W900 Controller Only)
Address Name
Data
Encoding
Permissions Value
0
Time On 32-Bit Integer Read Seconds
1
2
Total Time 32-Bit Integer Read Seconds
3
4
Output 32-Bit Float Read Percent
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Minimum Output 32-Bit Float Read/Write 0 – 100%
19
20
Maximum Output 32-Bit Float Read/Write 0 – 100%
21
22
Output Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
23
24
25
26
Hand Output 32-Bit Float Read/Write 0 – 100%
27
28
Hand Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
29
30
Reset Output Timeout
Boolean
Read/Write
Write 1 to Reset Output Timeout
31
32
Reset Time Total
Boolean
Read/Write
Write 1 to Reset Time Total
33 HOA Setting 16-Bit Integer Read/Write
0 = Hand, 1 = Off,
2 = Auto Mode
34
Status
16-Bit Status
Read
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.7 Analog Output Alarm Bitfield
When accessed as a Coil,
Returns 1 if any alarm is active
