5.3.6.4 Relay Output / Time Proportional Control Mode Address Map
Relay Output / Time Proportional Control Address Map
Address Name
Data
Encoding
Permissions Value
0
Time On
32-Bit
Integer
Read Seconds
1
2
Total Time
32-Bit
Integer
Read Seconds
3
4
Cycle Time
32-Bit
Integer
Read Seconds
5
6
Setpoint 32-Bit Float Read/Write Input Sensor Units
7
8
9
10
Proportional Band 32-Bit Float Read/Write Input Sensor Units
11
12
Current Cycle 32-Bit Float Read Seconds
13
14
Sample Period
32-Bit
Integer
Read/Write 10 – 86,399 Seconds
15
16
17
18
19
20
21
22
Output Time Limit
32-Bit
Integer
Read/Write 0 – 86,399 Seconds
23
24
25
26
27
28
Hand Time Limit
32-Bit
Integer
Read/Write 0 – 86,399 Seconds
29
30
Reset Output
Timeout
Boolean Read/Write Write 1 to Reset Output Timeout
31
Relay State
Boolean
Read
0 = Off, 1 = On
32
Reset Time Total
Boolean
Read/Write
Write 1 to Reset Time Total
33 HOA Setting
16-Bit
Integer
Read/Write
0 = Hand, 1 = Off,
2 = Auto Mode
34 Status
16-Bit
Status
Read See 5.4 Status Register Codes
35 Alarm Bitfield
16-Bit
Bitfield
Read
See 5.5.6 Relay Output Alarm Bitfield
When accessed as a Coil,
Returns 1 if any alarm is active
