5.3.6.2 Relay Output / On/Off & On/Off Disturbance Control Mode Address Map
Relay Output / On/Off & On/Off Disturbance Control Address Map
Address Name
Data
Encoding
Permissions Value
0
Time On 32-Bit Integer Read Seconds
1
2
Total Time 32-Bit Integer Read Seconds
3
4
5
6
Setpoint 32-Bit Float Read/Write Input Sensor Units
7
8
9
10
Deadband 32-Bit Float Read/Write Input Sensor Units
11
12
Duty Cycle 32-Bit Float Read/Write 0 – 100%
13
14
Duty Cycle Period
16-Bit Integer
Read/Write
0 – 3599 Seconds
15
16
17
18
On Time Delay 32-Bit Integer Read/Write 0 – 86,399 Seconds
19
20
Off Time Delay 32-Bit Integer Read/Write 0 – 86,399 Seconds
21
22
Output Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
23
24
25
26
27
28
Hand Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
29
30
Reset Output Timeout
Boolean
Read/Write
Write 1 to Reset Output Timeout
31
Relay State
Boolean
Read
0 = Off, 1 = On
32
Reset Time Total
Boolean
Read/Write
Write 1 to Reset Time Total
33 HOA Setting 16-Bit Integer Read/Write
0 = Hand, 1 = Off,
2 = Auto Mode
34
Status
16-Bit Status
Read
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.6 Relay Output Alarm Bitfield
When accessed as a Coil,
Returns 1 if any alarm is active
