5.3.7 Pulse Relay Output Address Maps
5.3.7.1 Pulse Relay Output / Manual Control Mode Address Map
Pulse Relay Output / Manual Control Address Map
Address
Name
Data Encoding
Permissions
Value
0
Time On 32-Bit Integer Read Seconds
1
2
Total Time 32-Bit Integer Read Seconds
3
4
Output 32-Bit Float Read Percent
5
6
7
8
9
10
11
12
13
14
15
16
17
18
On Time Delay 32-Bit Integer Read/Write 0 – 86,399 Seconds
19
20
Off Time Delay 32-Bit Integer Read/Write 0 – 86,399 Seconds
21
22
23
24
25
26
Hand Output 32-Bit Float Read/Write 0 – 100%
27
28
Hand Time Limit 32-Bit Integer Read/Write 0 – 86,399 Seconds
29
30
31
32
Reset Time Total
Boolean
Read/Write
Write 1 to Reset Time Total
33 HOA Setting 16-Bit Integer Read/Write
0 = Hand, 1 = Off,
2 = Auto Mode
34
Status
16-Bit Status
Read
See 5.4 Status Register Codes
35 Alarm Bitfield 16-Bit Bitfield Read
See 5.5.6 Relay Output Alarm Bitfield
When accessed as a Coil,
Returns 1 if any alarm is active
