Wascomat TD30 - Page 19

Installation manual
19
487 14 59 11 - TD30 TD50 TD75 US
1. Drum volume:
2. Weight:
Net
3. Drum:
Diameter
Depth
Revolutions per minute
4. Capacity:
5. Heat effect:
6. Air consumption:
7. Pipe connection:
Evacuation
8. Drop in pressure:
Evacuation max.
9. Gas pipe connection:
10. Gas pressure:
See page regarding pressure
11. Noise level:
TD30
TD50 TD75
286 L 528 L 650 L
220 kg 300 kg 325 kg
680 mm 913 mm 913 mm
790 mm 812 mm 998 mm
44 rpm 40 rpm 44 rpm
13.5 kg 23 kg 34 kg
21 kW 40 kW 57 kW
690 m
3
/h 1160 m
3
/h 1100 m
3
/h
Ø 200 Ø 200 Ø 200
20 Pa 60 Pa 340 Pa
ISO 7/1-R1/2 ISO 7/1-R1/2 ISO 7/1-R3/4
< 70 dB (A) < 70 dB (A) < 70 dB (A)
Gas heated - US only
Technical data - Gas heated dryer
Metric version (USA 60Hz)
