Wascomat TD30 - Gas Heated Dryer

Installation manual
487 14 59 11 - TD30 TD50 TD75 US
18
1. Drum volume:
2. Weight:
Net
3. Drum:
Diameter
Depth
Revolutions per minute
4. Capacity:
5. Heat effect:
6. Air consumption:
7. Pipe connection:
Evacuation
8. Drop in pressure:
Evacuation max.
9. Gas pipe connection:
10. Gas pressure:
Natural gas: Minimum
Maximum
Propane gas: Minimum
Maximum
11. Noise level:
TD30
TD50 TD75
Technical data - Gas heated dryer
Non metric version (USA 60Hz)
10.1 cu.ft. 18.6 cu.ft. 23 cu.ft.
485 lbs 662 lbs 717 lbs
26 3/4” 36” 36”
31” 32” 39 1/4”
44 rpm 40 rpm 44 rpm
30 lb 50 lb 75 lb
71600 BTU/h 136400 BTU/h 151200 BTU/h
410 cu.ft./min 680 cu.ft./min 650 cu.ft./min
Ø 8” Ø 8” Ø 8”
0.07” W.C. 0.23” W.C. 1.3” W.C.
1/2” NPT 1/2” NPT 3/4” NPT
3.5”W.C. 3.5”W.C. 3.5” W.C.
10” W.C. 10” W.C. 10” W.C.
8” W.C. 8” W.C. 8” W.C.
13” W.C. 13” W.C. 13” W.C.
< 70 dB (A) < 70 dB (A) < 70 dB (A)
Gas heated -US only
