Wascomat TD30 - Fuse Sizes, Effects and Voltages Type 50

Installation manual
47
487 14 59 11 - TD30 TD50 TD75 US
120V 1AC 60Hz 40 kW 1.0 kW 1.0 kW 15A
208-240V 1AC 60Hz 40 kW 1.0 KW 1.0 kW 15A
208-240V 3AC 60 Hz 40 kW 1.5 kW 1.5 kW 10A
400-480V 3AC 60Hz 40 kW 1.5 kW 1.5 kW 10A
120V 1AC 60Hz - 1.0 kW 1.0 kW 15A
208-240V 1AC 60Hz - 1.0 kW 1.0 kW 15A
208-240V 3AC 60Hz - 1.5 kW 1.5 kW 10A
400-480V 3AC 60Hz - 1.5 kW 1.5 kW 10A
208-240V 3AC 60Hz 24 kW 1.5 kW 25.5 kW 80A
400-480V 3AC 60Hz 24 kW 1.5 kW 25.5 kW 50A
208-240V 3AC 60Hz 30 kW 1.5 kW 31.5 kW 100A
400-480V 3AC 60Hz 30 kW 1.5 kW 31.5 kW 50A
Gas
Electric installation - Type 50
Fuse sizes, effects and voltages
Heating
Voltage Heat effect
kW
Motor effect
kW
Max.
effect
kW
Circuit
breaker
Steam
Electric
