Wascomat TD30 - Electric Heated Dryer

Installation manual
487 14 59 11 - TD30 TD50 TD75 US
20
1. Drum volume:
2. Weight:
Net
3. Drum:
Diameter
Depth
Revolutions per minute
4. Capacity:
5. Heat effect:
6. Air consumption:
(BTU/h) - cu.ft./min
(BTU/h) - cu.ft./min
7. Pipe connection:
Evacuation
8. Drop in pressure:
Evacuation max.
9. - -
10. - -
11. Noise level:
TD30
TD50 TD75
Technical data - Electric heated dryer
Non metric version (USA 60Hz)
10.1 cu.ft. 18.6 cu.ft. 23 cu.ft.
485 lbs 662 lbs 750 lbs
26 3/4” 36” 36”
31” 32” 39 1/4”
44 rpm 40 rpm 44 rpm
30 lb 50 lb 75 lb
46100 BTU/h 81900 BTU/h 102400 BTU/h
61500 BTU/h 102400 BTU/h 122900 BTU/h
(46100) - 250 (81900) - 490 (102400) - 650
(61500) - 410 (102400) - 620 (122900) - 650
Ø 8” Ø 8” Ø 8”
0.32” W.C. 0.8”W.C. 1.3” W.C.
< 70 dB (A) < 70 dB (A) < 70 dB (A)
Electric heated - US only
