Wascomat TD30 - Page 21

Installation manual
21
487 14 59 11 - TD30 TD50 TD75 US
1. Drum volume:
2. Weight:
Net
3. Drum:
Diameter
Depth
Revolutions per minute
4. Capacity:
5. Heat effect:
6. Air consumption:
(kW) - m
3
/h
(kW) - m
3
/h
7. Pipe connection:
Evacuation
8. Drop in pressure:
Evacuation max.
9. - -
10. - -
11. Noise level:
TD30
TD50 TD75
286 L 528 L 650 L
220 kg 300 kg 340 kg
680 mm 913 mm 913 mm
790 mm 812 mm 998 mm
44 rpm 40 rpm 44 rpm
13.5 kg 23 kg 34 kg
13.5 kW 24.0 kW 30.0 kW
18.0 kW 30.0 kW 36.0 kW
(13.5) - 430 (24.0) - 840 (30.0) - 1100
(18.0) - 690 (30.0) - 1060 (36.0) - 1100
Ø 200 Ø 200 Ø 200
80 Pa 200 Pa 340 Pa
< 70 dB (A) < 70 dB (A) < 70 dB (A)
Electric heated - US only
Technical data - Electric heated dryer
Metric version (USA 60Hz)
