Wascomat TD30 - Gas Installation; Tables of Pressure and Adjustments

Installation manual
487 14 59 11 - TD30 TD50 TD75 US
42
Gas installation
Tables of pressure and adjustments
Gas type Upper calorific Gas pressure Ø
value Inlet Nozzle
21
MJ/m3 inch W.C. inch W.C. **mm
Propane 93.7 11.0 11.0 2.4
Natural gas 37.78 7.0 4.2 3.8
Propane 93.7 11.0 11.0 3.4
Natural gas 37.78 7.0 3.2 5.6
Propane 93.7 11.0 11.0 3.5
Natural gas 37.78 7.0 3.2 5.8
Nozzle pressure
( Outlet pressure tap )
5
Dryer
type
Heating
power
50
75
136400
151200
Btu/h
30
71600
** Nozzle dimension at altitude up to 1999 ft.
