Wascomat TD30 - Fuse Sizes, Effects and Voltages Type 30

Installation manual
487 14 59 11 - TD30 TD50 TD75 US
46
120V 1AC 60Hz 21 kW 0.7 kW 0.7 kW 15A
208-240V 1AC 60Hz 21 kW 0.7 kW 0.7 kW 15A
208-240V 3AC 60Hz 21 kW 1.5 kW 1.5 kW 10A
400-480V 3AC 60Hz w/reversing 21 kW 1.5 kW 1.5 kW 10A
400-480V 3AC 60Hz wo/reversing 21 kW 1.0 kW 1.0 kW 10A
120V 1AC 60Hz - 0.7 kW 0.7 kW 15A
208-240V 1AC 60Hz - 0.7 kW 0.7 kW 15A
208-240V 3AC 60Hz - 1.5 kW 1.5 kW 10A
400-480V 3AC 60Hz w/reversing - 1.5 kW 1.5 kW 10A
400-480V 3AC 60Hz wo/reversing - 1.0 kW 1.0 kW 10A
208-240V 3AC 60Hz 13.5 kW 1.0 kW 14.5 kW 50A
400-480V 3AC 60HZ 13.5 kW 1.5 kW 15.0 kW 25A
208-240V 3AC 60Hz 18 kW 1.0 kW 19.0 kW 50A
400-480V 3AC 60Hz 18 kW 1.5 kW 19.5 kW 35A
Gas
Steam
Electric
Heating
Electric installation - Type 30
Fuse sizes, effects and voltages
Voltage
Heat effect
kW
Motor effect
kW
Max.
effect
kW
Circuit
breaker
