Installation manual
23
487 14 59 11 - TD30 TD50 TD75 US
1. Drum volume:
2. Weight:
Net
3. Drum:
Diameter
Depth
Revolutions per minute
4. Capacity:
5. Heat effect:
Depend upon steam pressure
6. Air consumption:
7. Pipe connection:
Evacuation
8. Drop in pressure:
Evacuation max.
9. Steam pipe connection:
Steam
Outlet
10. Steam:
Recommended pressure (absolute)
Max. allowable pressure
11. Noise level:
TD30
TD50 TD75
Technical data - Steam heated dryer
Metric version (USA 60Hz)
286 L 528 L 650 L
220 kg 340 kg 345 kg
680 mm 913 mm 913 mm
790 mm 812 mm 998 mm
44 rpm 40 rpm 44 rpm
13.5 kg 23 kg 34 kg
925 m
3
/h 1380 m
3
/h 1100 m
3
/h
Ø 200 Ø 200 Ø 200
80 Pa 200 Pa 340 Pa
ISO 7/1-Rp1/2 ISO 7/1-Rp3/4 ISO 7/1-Rp3/4
ISO 7/1-Rp1/2 ISO 7/1-Rp3/4 ISO 7/1-Rp3/4
100-1000 kPa 100-1000 kPa 100-1000 kPa
1000 kPa 1000 kPa 1000 kPa
< 70 dB (A) < 70 dB (A) < 70 dB (A)
Steam heated - US only
