Page 70 of 102 Page 71 of 102Doc: DRX Installation
Version: 7.1 January 2021
Doc: DRX Installation
Version: 7.1 January 2021
wassp.com wassp.com
DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL
260mm
216mm
175mm
Figure 36. DRX-46 Front Plate Dimensions
260mm
216mm
175mm
Figure 37. DRX-46 Back Plate Dimensions
