Wassp DRX - Outline Drawings

Page 68 of 102 Page 69 of 102Doc: DRX Installation
Version: 7.1 January 2021
Doc: DRX Installation
Version: 7.1 January 2021
wassp.com wassp.com
DRX INSTALLATION MANUAL DRX INSTALLATION MANUAL
AUXN2K
POWER
LAN
0183
RS232
RS422-A RS422-B
260mm
216mm
132mm
Figure 34. DRX-32 Back Plate Dimensions
8.2. DRX46 OUTLINE DRAWINGS
11.50
6.60
244.00
132.50
265.00
6.40
20.50
155
216
216.00 260.00
175
377.00
F
E
4
2
1
7
5
3
8
6
B
C
D
A
1 OF 2
A3
CHECKED BY
DESCRIPTION
PART NUMBER
REVISION
DRAWN BY
MATERIAL
SHEET
SIZE
DATE 16-05-2018
David Williams
B
C
D
E
F
A
1
8
6
7
5
4
3
2
GENERAL NOTES:
PART MUST BE CLEAN WITH NO SINKS, FLASH, SHARP EDGES OR BURRS
1.
ALLOWED. ALL DIMENSIONS ARE IN MILLIMETRES UNLESS OTHERWISE SPECIFIED.
2.
ALL DIMENSIONS AND TOLERANCES TO APPLY AFTER FINAL TEXTURING
3.
AND SURFACE FINISHING. REFER TO CAD DATA FILE
4.
(Assem1 - ENL Extrusion - 20171024.IGES/.STEP/.X_T) FOR MISSING DIMENSIONS. UNLESS OTHERWISE STATED, ONLY USE RoHS COMPLIANT MATERIAL.
5.
COPYRIGHT : THIS DRAWING AND DETAIL ARE PROPERTY OF ELECTRONIC NAVIGATION LTD. AND MAY NOT BE REPRODUCED IN WHOLE OR PART
WITHOUT THE WRITTEN PERMISSION OF ELECTRONIC NAVIGATION LTD. - EMAIL enl@enl.co.nz AUCKLAND, NEW ZEALAND.
CLIENT
FINISH
COLOUR
Note: All Equipment Cases to be Earthed
(5) Equip supplier install reqmts
(4) NZ Maritime Rules - per TRS
(3) IEC60533 for EMI/EMC - per TRS
(2) IEC Stds, IMO & SOLAS - per TRS
(1) LRS +100A1 SSC Patrol Mono HSC LDC G3, LMC UMS
Installation to comply with applicable cl of:
Figure 35. DRX-46 Assembly
