9.2. DRX46 INTERCONNECTION
1
2
3
4
5
6
7
8
LAN
TD_P
TD_N
RD_P
NC
NC
RD_N
NC
NC
8
9
10
1
2
3
4
5
6
7
AUX
KP1_IN
KP1_IN_GND
KP2_IN
KP2_IN_GND
KP1_OUT
+5.5V Isolated
GND(5.5V,KPI_OUT)
REMOTE_PWR_ON
REMOTE_PWR_ON_GND
NC
1
2
3
4
5
6
7
8
0183
NMEA0183 IN-B
NMEA0183 IN-A
NMEA0183 OUT-B
NMEA0183 OUT-A
GND (SHIELD)
PPS_IN
PPS_IN GND
NC
BLACK
BROWN
WHITE
BLUE
RED
GREY
YELLOW
GREEN
1
2
3
4
5
6
RS232
RS232_TX
RS232_RX
RS232_GND
NC
9-32V+
9-32V-
BLUE
GREEN
YELLOW
BLACK
RED
WHITE
9
1
2
3
4
5
6
7
8
RS422-A
PPS (AUX)
RxD B
RxD A
TxD B
TxD A
GND
NC
9-32V+
9-32V-
BROWN
BLUE
WHITE
GREEN
YELLOW
GREY
1
2
3
4
9
10
11
12
1
2
3
4
5
6
7
8
RS422-B
PPS (AUX)
RxD B
RxD A
TxD B
TxD A
GND
RESERVED
RESERVED
RESERVED
RESERVED
9-32V-
9-32V+
1
2
3
4
5
N2K
SHIELD
NET S
NET C
NET-H
NET-L
BARE
RED
BLACK
WHITE
BLUE
1
2
POWER
DC +VE
DC -VE
WHITE
BLACK
FAN
12V+
12V+
12V-
12V-
Figure 40. DRX-46 Interconnection Diagram
10 TECHNICAL SPECIFICATIONS
DRX Spec Sheet
System
- Frequency Variable, Wideband, Transducer Dependent
- Signal Type DRX-32, WSP-603-20X; FM
DRX-46, WSP-603-25X; FM/CW
- Tx Type DRX-32, WSP-603-20X; Full Digital
DRX-46, WSP-603-25X; Digital
- Ping Rate Automatic, depth determined; Maximum 50Hz
- Depth Range Transducer and environmental dependent. Nominally:
DRX-32, WSP-603-20X; 1-200m (WMB160). 2-450m (WMB80)
DRX-46, WSP-603-25X; 1-400m (WMB160). 2-600m (WMB80)
-Range Resolution Maximum 2cm
I/O Interface
- Ethernet GbE
- Serial RS-232, RS-422 x 2 (model dependent), NMEA 0183
- CAN NMEA 2K
- Analog KP in x2, KP out, PPS
- Other Remote Power Control, Fan Power out 12V x2 (model dependent)
Data Formats
- Input Sentences See “Appendix B - Supported Sensors and Sentences” on page 87
- Output Sentences See “Appendix B - Supported Sensors and Sentences” on page 87
- Output Data types See WASSP DRX ICD (Interface documentation for DRX and associated
DRX SDK/API documentation)
Power
- Power Supply DC Input
DRX-32, WSP-603-20X; 9-32V DC
DRX-46, WSP-603-25X; 18-32V DC
- Power Consumption (max) DRX-32, WSP-603-20X (S3,F3,F3L) Peak operating power: 36W
Average operating power: 30W
DRX-46, WSP-603-25X
(S3X,F3X,F3XL)
Peak operating current: 6.5 Amps
Average operating power: 70W
Mechanical
- Dimensions DRX-32, WSP-603-20X; DRX377mm(L) x 260mm(W) x 132mm (H)
DRX-46, WSP-603-25X; DRX377mm(L) x 260mm(W) x 175mm (H)
- Weight DRX-32, WSP-603-20X; 8.3kg
DRX-46, WSP-603-25X; 9.5kg
- Mounting Bulkhead or Flat
Environmental
- Operating Temperature DRX-32, WSP-603-20X; 0
o
C to 50
o
C
DRX-46, WSP-603-25X; 0
o
C to 50
o
C
- Storage Temperature -20
o
C to 85
o
C
- Ingress/Water Impact* IP53, Bulkhead Mounted
- Humidity/Damp Heat IEC60945
+40°C 93 % relative humidity
- Vibration DRX-32, WSP-603-20X; “IEC60945 Sweep 2 Hz – 13,2 Hz at ± 1 mm, 13,2
Hz – 100 Hz at 7 m/s2 and for 2 h on each resonance, otherwise 2 h at
30 Hz in all three axes”
- Shock DRX-32, WSP-603-20X; MIL-STD-901, Grade B, Class II
- EMC IEC60945
*Extended ingress rating to IP67 available; model WSP-603-205
