2-4 Setting Up the Detector
Detector dimensions
The following figure shows the dimensions of the detector.
Detector dimensions
Connecting to the electricity source
The 2998 PDA detector requires a separate, grounded electricity source. The
ground connection in the electrical outlet must be common and connected near
the system.
Warning: Avoid electrical shock:
• Use power cord SVT-type in the United States and HAR-type or
better in Europe. For other countries, contact your local Waters
distributor.
• Power-off and unplug the detector before performing any
maintenance on the instrument.
• Connect the detector to a common ground.
TP02753
34.3 cm
(13.5 inches)
19.1 cm
(7.64 inches)
61 cm
(24 inches)
