1.1 ACQUITY RDa Detector Front Panel Overview
Figure 1–1: ACQUITY RDa with the instrument door closed
Instrument display Calibration reservoir
bottle
Wash reservoir bottle Air filter
Lock mass reservoir
bottle
Power button
Instrument door handle
