Waters ACQUITY RDa - Instrument Display

Figure 1–2: ACQUITY RDa with the instrument door open
Divert valve Leak sensor
Source Air filter
1.2 Instrument display
The symbols on the ACQUITY RDa Detector's front panel display the current operating status of
the system and its components:
• Initializing
• Ready
August 20, 2021, 715005003 Ver. 04 (Previously released as Revision C)
Page 17
