Notice: To avoid damage to the electrical connector's screws, do not
overtighten them.
11. Connect the electrical cable to the socket on the right-hand side of the instrument's front
panel and tighten the screws.
12. To avoid trapping and damaging the capillary in the instrument door, slide the capillary
beneath the retaining clips.
13. Close the instrument door.
14. In the software, click Operate to put the instrument into Operate mode.
Note: When transitioning from Power Save mode to Operate mode, Waters recommends
that you allow the instrument to stabilize for one hour before you perform a calibration.
3.12 Replacing the probe capillary assembly
Warning: To avoid puncture injuries from the sharp probe capillary, use care when
inserting it into the source enclosure.
Important: To avoid damaging the fragile probe capillary, if the instrument is situated above eye
level, disconnect the source enclosure and place it on a bench top or other surface so that you
can exercise caution when inserting the probe (see Removing the source enclosure from the
instrument (Page 28)).
Required tools and materials
• Chemical-resistant, powder-free gloves
• Replacement probe capillary
To replace the probe capillary assembly:
1. In the UNIFI software, click Power Save to put the instrument in Power Save mode.
2. Open the instrument door.
August 20, 2021, 715005003 Ver. 04 (Previously released as Revision C)
Page 52
