D.2 Connecting the Edwards oil-filled backing pump
Figure D–2: Connecting the backing pump
Exhaust port
Vacuum hose assembly
Power cable connector
Required tools and materials
• Chemical-resistant, powder-free gloves
• 7-mm nut driver
• 8-mm hex wrench
• Utility knife
• NW25 clamp (included in the installation kit)
August 20, 2021, 715005003 Ver. 04 (Previously released as Revision C)
Page 90
