Figure 3–3: Removing the gas cone and the PEEK cone clamp
PEEK cone clamp
Gas cone
Ion block
Notes:
• The gas cone conceals the sample cone assembly, which contains the aperture disc.
• If the aperture disc becomes separated from the rubber carrier, simply re-insert the disc
into the carrier.
3. Remove the sample cone assembly from the gas cone.
Figure 3–4: Sample cone assembly components
August 20, 2021, 715005003 Ver. 04 (Previously released as Revision C)
Page 34
