Figure 3–14: Ion guide – electrical connectors
2-way connector –
top view
6-way connectors –
top view
6-way connectors –
underside view
Wire routing notch
Note: Ensure that you route the wire for the 2-way connector through the wire routing
notch.
5. Fit the differential aperture O-ring to the differential aperture support.
Note: If the O-ring is visibly damaged, replace it.
Figure 3–15: Fitting the O-ring and differential aperture
Electrical connectors Ion guide support
rods
August 20, 2021, 715005003 Ver. 04 (Previously released as Revision C)
Page 48
