Note: Ensure that there is a negative gradient between the exhaust port and the trap
bottle inlet.
Figure D–7: Location of source exhaust port
Source exhaust port
Nitrogen outlet
Figure D–8: Exhaust trap bottle
From instrument exhaust port (3/8-inch convoluted tubing)
August 20, 2021, 715005003 Ver. 04 (Previously released as Revision C)
Page 96
