Waters Xevo TQ-S cronos

To Next Page

To Previous Page

Figure 3–2: Probe adapter types

ESI probe adapter

APCI probe adapter

ESI identification label

APCI probe heater

ESI probe tip

APCI identification label

January 10, 2022, 715006200 Ver. 01 (previously released as Rev. A)

Page 49
