Installing and removing the corona pin
January 11, 2016, 715004599 Rev. B 103
5. Close the source enclosure.
6. Look through the source window, and use the vernier probe adjuster to position the
probe tip so that it is pointing approximately midway between the tips of the sample
cone and corona pin.
Removing the corona pin from the source
Required material
Chemical-resistant, powder-free gloves
To remove the corona pin from the source:
1. Prepare the instrument for working on the source (see page 97).
2. Pull the source enclosure release (located at the bottom, right-hand side) outward,
and swing open the enclosure.
3. Remove the corona pin from its mounting contact (see the figure on page 103).
Tip: Store the corona pin in a safe location.
4. Fit the blanking plug to the corona pin mounting contact (see the figure on
page 102).
5. Close the source enclosure.
Warning: To avoid personal contamination with biologically hazardous, or
toxic materials, and to avoid spreading contamination to uncontaminated
surfaces, wear clean, chemical-resistant, powder-free gloves while performing
this procedure. The LC system connections, ESI probe, and source can be
contaminated.
Warning: To avoid electric shock, ensure that the instrument is prepared for
working on the source before commencing this procedure.
Warning: To avoid burn injuries, take great care while working with the
instrument’s source enclosure open; the source can be hot.
Warning: To avoid puncture wounds, take great care while working with
the source enclosure open if an ESI probe is fitted; the ESI probe tip is sharp.
