Watson-Marlow 630 U - 30 Tube Replacement Procedures; 30.1 Continuous Tubing

30 Tube replacement
Always isolate the pump from the mains power supply before opening any
guard or track, or performing any positioning, removal or maintenance
operation.
30.1 Continuous tubing
620R
1. 2. 3.
4. 5. 6.
620L
1. 2. 3.
4. 5.
≤8.0mm=230mm ,
12mm/16mm=240mm
m-630un-en-08 167
