14.6 Input/output connectors - IP66

Key to symbols

Run Input Keypad direction change

Stop Output Dry (no leak)

Clockwise rotation Manual (keypad) control Wet (leak detected)

Anticlockwise rotation Analogue

Connector

No.

Function Input

output

Configurable

Signal response

J1 No Connection to pump

AN1+P

ANALOGUE 1

0VA

Input Yes

AN2+P

ANALOGUE 2

0VA

Input Yes

Standard N Module: Input/output Connectors

60 m-630un-en-08
