Connector

No.

Function Input

or

output

Configurable

Signal response

J4

SP

LK

STOP/LEAK

22V

SP

LK

STOP/LEAK

22V

VDC

+

-

VDC

+

-

Input Yes

J5

PRESS

0VA

PRESS/FREQ

FREQ

VDC

+

-

+

-

PRESS

0VA

PRESS/FREQ

FREQ

22V

200Hz

1KHz

Input Yes

J6 1.Earth

2.Earth

No

m-630un-en-08 61
