Key to symbols
Run Input Keypad direction change
Stop Output Dry (no leak)
Clockwise rotation Manual (keypad) control Wet (leak detected)
Anticlockwise rotation Analogue
Wiring the D connector
Signal Name
Input or
output
Configurable Signal response
1
5
6
9
+
-
0V
ANALOGUE 1
Input Yes
1
5
6
9
+
-
ANALOGUE 2
0V
Input Yes
