ProtoNode FPC-N34 & FPC-N35 User Manual

APPENDIX I: AM ERROR, STATE AND STATUS TABLES

OMM-0150_B • 5/20/2021 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 135 of 140

The diagram below shows MODBUS connection for AM Series boilers with serial number above

15000000.

Figure I-2: MODBUS connection to AM Series boilers with serial number > 15000000
