• Battery: battery charge level.
• Probe information: serial number of the eld probe attached to the apparatus
and its frequency information.
Measurement information:
• Logging and average parameters:
1. Average window time.
2. Average type (sliding or tumbling).
3. Sampling rate.
4. Logging time.
Field information: (updated twice per second)
The SMP2 has a double screen display. Depending on the probe selected, you
have the RMS and Peak values or RMS and Average values.
• Total eld: instantaneous total eld level.
Obtained for three-axis probes as:
• The quadratic sum of each axis eld (for eld intensity units):
• The quadratic sum of each axis eld (for eld intensity units):
• Field unit: unit of measurement of the eld value shown on the display.
This unit applies to the total eld, the eld on each axis and the maximum,
minimum and average values.
Battery
discharged
Battery
charging
Battery
fully charged
User’s Manual Electromagnetic Field Meter SMP2 P. 18
