Maximum, minimum and average values: these values (below the total eld
values) are initialized when beginning a new log or can also be initialized with
the virtual button “Reset”. Average value is updated depending on the type of
averaging and interval chosen in the Measurement Options.
• Field on each axis: the eld measured on each axis for isotropic three-axis
probes. Updated twice per second.
Graph:
In the time domain:
It shows a graphical view of the temporal evolution of the eld. It represents
the last measurements. This time scale can be modied in the settings menu
(graph timespan).
“MENU” “SETTINGS” “Graph timespan”
In the frequency domain:
It shows the frequency information of the signal (horizontal axies value depend
on the span). Also a vertical line represents the position of the cursor (with the
associated information on the right top side of the graph).
GPS information:
Positioning information provided by the GPS receiver. This information is only
displayed when the GPS is switched on.
• Lat: latitude.
• Lon: longitude.
On the right side a colour indicates the quality of the position:
• Red: bad.
• Orange: average.
• Green: good.
Functions:
These menus depend on the probe connected but general functions are as
follows:
• Menu: access to the menu screen.
• Log: start a new measurement.
User’s Manual Electromagnetic Field Meter SMP2 P. 19
