Call from Base Station
WHY?

Test whether the base station sets up a call to the
mobile.

Proper call setup is a requirement for further tests.
Requirement

The mobile is not in an analog or digital traffic channel.
In any other case drop the call with
{RELEASE}
.

The mobile is not in test mode.
HOW?

Make the general test preparations.

Press
{CELL.}
in the basic test mask.

Lift the handset when the mobile rings or the "Call
Received" indicator symbol lights up. Then the mobile is
handed off to the selected analog or digital traffic chan-
nel. Now the display will show the test results.
Test Results
A
+
D
RESULt1 MIN
IMSI
Received mobile station identification (MIN or IMSI).
RESULt2
RESULt3
SN 1st line: Serial number of mobile (hexadecimal code).
2nd line: Serial number of mobile (decimal code).
RESULt5 SCM Station class mark
1st character: power class
(1 = high, 2 = medium, 3 = low, 4 = very low)
2nd character: transmit mode
(blank = continuous, D = discontinuous)
3rd character: RF bandwidth
(blank = 20 MHz, E = extended = 25 MHz)
4th character: mobile type
(0 = analog mobile; 1 = IS-136 mobile)
A
MTXOFFset ERR Frequency error of mobile transmitter in actual analog TC.
MDEMOD DEV Mobile frequency deviation in actual analog TC.
MPOWER PWR Mobile output power in actual analog TC (average value).
Power must correspond to entered power level (see appendix).
D
RESULt6 ERR Frequency error of mobile transmitter in actual digital TC.
RESULt7 PWR Mobile output power in actual digital TC (average value).
Power must correspond to entered power level (see appendix).
RESULt8 DCC Digital color code. Value must be same as entered DVCC.
