5110326C_OI-II_Webasto Live 35
There also is a data line in the charging
cable together with the power supply lines
and is known as a CP (control pilot) line.
This line (black-white) is inserted into the
push-in terminal on the CP connection .
This applies to installing the original char-
ging cable and also to replacing the char-
ging cable.
3.2 Description of power
supply interface
connections
See also Fig. 4
The connections of the mains cable are
marked with "IN". The 5 terminals on the
left have L1/L2/L3/N/PE printed on them
The connections of the charging cable are
marked with "OUT". The 5 terminals on the
right have PE/N/L1/L2/L3 printed on them
NOTE
To release the power supply connec-
tions, use an insulated flat-head
screwdriver by inserting it into the
opening for this purpose immediately
above push-in terminal.
All dimensions specified in mm.
3.3 Electricity meter
With the integrated MID-compliant power
meter, it is possible to measure power con-
sumption by loading with the Webasto Live.
The calibration date for the power meter
can be found on the type plate on the char-
ging station, below the CE mark. When us-
ing the power meter, pay careful attention
to the country-specific legal calibration stip-
ulation.
4 Scope of delivery
Scope of delivery Amou
nt
Charging station
1
Charging cable with charging coupling
1
RFID dongle
2
Installation kit for wall mounting
Wall plug (8 x 50 mm, Fischer
UXR8)
4
Screw (6 x 70, T25)
2
Screw (6 x 90, T25)
2
Washer (12 x 6.4 mm, DIN 125-A2)
4
Screw (3 x 20 mm, T10)
2
Mounting bracket
1
Cable bushing, (one is custom-
made)
2
Installation kit for charging cable:
Spiral antikink protection
1
Cable tie
1
Strain relief clamp
1
Screw (6.5x25mm, T25) for
fastening the strain relief clamp
2
Scope of delivery Amou
nt
Operating and installation instructions
1
Table1: Scope of Delivery
5 Required tools
Tool description Amou
nt
Slot-head screwdriver 0.5x3.5mm
1
Torx screwdriver Tx25
1
Torx screwdriver Tx10
1
Torque wrench (range covers 5-6Nm,
for Tx25)
1
Torque wrench (range covers 4-5Nm,
for open-ended spanner size 29)
1
Drilling machine with 8 mm drill
1
Hammer
1
Measuring tape
1
Spirit level
1
Wire stripping tool
1
Installation tester
1
EV simulator with rotary field display
1
Round file
1
Combination pliers
1
6 Installation and
electrical connection
Observe the safety information provided
here "Safety on page 31".
