Webasto Live Installation Instructions

EN
46 5110326C_OI-II_Webasto Live
Descrip-
tion
Data
Protection
against
mechan-
ical impact
IK08
Operating
temperat-
ure range
[°C]
-25 to +40 (without direct solar radi-
ation)
Storage
temperat-
ure range
[°C]
-25 to +70
Permiss-
ible relat-
ive humid-
ity [%]
5 up to 95 Non-condensing
Altitude
[m]
max. 2,000 (above sea level)
Tested
OCPP-
backends
Allego, has.to.be, Fortum, Bouygyes,
Virta, ChargeCloud, Ladenetz,
ChargeIT, NTT, Driivz, new motion,
Vattenfall, Char.gy
RFID
MODULE,
Frequency
range /
Field
strength
13.56 MHz / - 14dBµA/m (3m)
WiFi
(WLAN),
Frequency
2.4 GHz, Channel 1-13 (2.412 – 2.472
GHz)
[< 150 mW]
Descrip-
tion
Data
range
[max.
transmit-
ting
power]
LTE FDD,
Frequency
range /
Transmit-
ting
power
[max.
transmit-
ting
power]
B1 (Rx: 1920-1980 MHz, Tx:
2110-2170 MHz) / - 101.5 dBm (10m)
B3 (Rx: 1805-1880 MHz, Tx:
1710-1785 MHz) / - 101.5 dBm (10m)
B5 (Rx: 869-894 MHz, Tx: 824-849
MHz) / - 101 dBm (10m) B7 (Rx:
2620-2690 MHz, Tx: 2500-2570
MHz) / - 99.5 dBm (10m)
B8 (Rx: 925-960 MHz, Tx: 880-915
MHz) / - 101 dBm (10m) B20 (Rx:
791-821 MHz, Tx: 832-862 MHz) / -
102.5 dBm (10m)
[< 200 mW]
UMTS /
WCDMA,
Frequency
range /
Transmit-
ting
power
[max.
transmit-
ting
power]
B1 (Rx: 1920-1980 MHz, Tx:
2110-2170 MHz) / -110 dBm (10m)
B5 (Rx: 869-894 MHz, Tx: 824-849
MHz) / - 110 dBm (10m)
B8 (Rx: 925-960 MHz, Tx: 880-915
MHz) / - 110.5 dBm (10m)
[< 250 mW]
GSM, Fre-
quency
range /
Transmit-
B3 (Rx: 1805-1880 MHz, Tx:
1710-1785 MHz) / - 109 dBm (10m)
B8 (Rx: 925-960 MHz, Tx: 880-915
MHz) / - 109 dBm (10m)
Descrip-
tion
Data
ting
power
[max.
transmit-
ting
power]
[< 2 W]
15 Check list for the
installation of the
Webasto charging
station
Charging sta-
tion
Webasto Live
Charging
power
11 kW 22 kW
Serial number
Material num-
ber
General :
Installation, electrical connection and initial
operation of the charging station must be
carried out by an electrician.
Local conditions:
The charging station has not been installed in
an explosion sensitive area (EXzone).
The charging station has been installed in a
location where falling objects cannot damage
the charging station.

Webasto Live Specifications

General

Charging Power	Up to 22 kW
Connector Type	Type 2
App Support	Yes (Webasto ChargeConnect)
Load Management	Dynamic load management (optional)
Charging Mode	Mode 3
User Authentication	RFID, App
Output Voltage	400V AC
Output Current	Up to 32A
Power	Up to 22 kW
