Webasto Live Installation Instructions

EN
42 5110326C_OI-II_Webasto Live
Operat-
ing in-
dicator
Description
C3 LED lights up red for 0.5s at 60-
second intervals:
Information about lost GSM signal
(every 60 s in all modes) (indicator in
configuration can be activated)
C5 LED flashes blue for 0.5s and red for
0.5s:
RFID dongle is not permitted by ser-
vice provider or charging station.
C6 LED flashes blue for 1s and green for
1s and a beep sounds:
Authorisation was successful. The
vehicle must be connected to the
charging station within 45s (default
value).
C7 LED flashes green at 0.5 second inter-
vals:
Increasing state of charge (SOC) with
available connection using ISO15118,
12.5% SOC per LED, increasing stead-
ily periodically.
C8 LED is purple for 4 s and an acoustic
signal sounds for 1.5 - 1 - 0.5 s:
Reset by backend.
Table5: Communication
7.2 Start charging
NOTE
Always take into account the vehicle
requirements before charging a
vehicle.
NOTE
Park the vehicle for charging such as
to avoid strain in the charging cable.
See also Fig. 11
The RFID dongle can be authorised before or
after the charging cable is plugged into the
vehicle. Note that the time between author-
isation and connection of the charging cable
is limited to 45s (default value). After this
period, the authorisation is no longer valid,
and the charging station returns to the start-
ing state.
Action Description
u
Hold the
RFID
dongle to
the card
reader
The user is enabled.
u
Connect
the char-
ging coup-
ling to the
vehicle.
Charging station performs sys-
tem and connection tests.
LED is blue then switches to
green: Charging mode
7.3 Stop charging
7.3.1 The vehicle has stopped the
charging cycle automatically:
Action Description
The vehicle has stopped the
charging cycle automatically,
then:
u
Unlock the car if neces-
sary.
u
Unplug the charging
coupling from the
vehicle.
u
Lock charging coupling in
the holder of the char-
ging station.
LED flashes blue
at 1 second in-
tervals. Vehicle
connected, not
charging.
7.3.2 If the vehicle does not
automatically stop the
charging cycle:
Action Description
u
Hold the
RFID
dongle to
the card
reader
Charging cycle is stopped. LED
flashes green and slowly
changes to blue
Or
u
Stop char-
ging cycle
at vehicle.
Charging cycle is stopped. LED
flashes green and quickly
changes to blue.
The charging station can now be restarted.

Webasto Live Specifications

General

Charging Power	Up to 22 kW
Connector Type	Type 2
App Support	Yes (Webasto ChargeConnect)
Load Management	Dynamic load management (optional)
Charging Mode	Mode 3
User Authentication	RFID, App
Output Voltage	400V AC
Output Current	Up to 32A
Power	Up to 22 kW
