Webasto thermo top evo Installation Documentation

Audi A1
Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
11
1 Passenger compartment relay and
fuse holder
2 M6x30 bolt, large diameter washer,
original vehicle hole, 10mm spacer,
flanged nut
Installing
passenger
compart-
ment relay
and fuse
holder
1 Wiring harness of passenger com-
partment relay and fuse holder
2 Wiring harness of heater
Connecting
same colour
wires of wir-
ing harness-
es
1 Remove LWR control unit
Removing
control unit
1
6-pin connector T6y
Removing
fan unit
connector
16
2
1
17
1
2
18
1
19
1
