Audi A1
Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
5
Preliminary Work
Vehicle
• Open the fuel tank cap.
• Ventilate the fuel tank.
• Close the fuel tank cap again.
•Depressurise the cooling system.
• Disconnect the battery.
• Remove the windscreen wipers.
• Remove the coolant reservoir cap.
• Remove the drain pipe of the air filter box.
• Remove the air filter (not in case of 1.4TDI).
• Remove the air filter intake hose (not in case of 1.4TDI).
• Remove the engine control unit.
• Remove the coolant reservoir partition wall.
• Remove the windscreen wiper motor.
• Remove the left front wheel.
• Remove the left wheel-well inner panel.
• Remove the horn(s) (there can be one or two) together with the bracket.
• Remove the underride protection.
• Remove the right vehicle underbody trim.
• Remove the left and right lateral instrument panel trim.
• Remove the lower instrument panel trim on the left.
• Remove the glove box completely.
• Fold up the seating area of the rear bench seat or remove it (depends on the equipment).
• Open the tank-fitting service lid.
Heater
• Remove years that do not apply from the type and duplicate label.
• Attach the duplicate label (type label) visibly in the appropriate place in the engine compart-
ment.
Heater Installation Location
1 Heater
Installation
Location
