Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
31
Audi A1
Work step F8.
Checking
firm seating
of FuelFix
1 Cable tie as tension relief
2 Fuel line of FuelFix
Securing
fuel line
Installing FuelFix for Diesel
Vehicles
X =
Drilling tem-
plate
Work steps F1 and F2.
Move label
4 as shown.
1 Fuel tank sending unit
2 Position 22mm template at raised
parts
3 Hole pattern
F
Fuel extrac-
tion
92
93
2
1
94
X
95
2
4
1
22
2
22
3
