Webasto thermo top evo

Ident. No.: 1324052C_EN Status: 06.10.2016 © Webasto Thermo & Comfort SE
58
Audi A1
Diesel
1
Underride protection
2 Remove insulation
Hole in un-
derride pro-
tection
1 Hole (as per work step 1 of the instal-
lation instructions)
Hole in un-
derride pro-
tection
Petrol and diesel
Position exhaust end fastener 1 as per
work step 3 of the installation instructions
and copy hole pattern
2 [2x].
Copying
hole pattern
Hole 1 [2x] as per work step 4 of the instal-
lation instructions.
Holes in un-
derride pro-
tection
182
1
2
183
1
35
60
2
184
2
1
1
185
1
